Vega M

Vega M is a versatile street- and area luminaire that adapts to your future Smart City needs. The design and technical features of the luminaire are perfect for Scandinavian conditions. The luminaire has a smooth body that keeps any trash from clinging to it. Vega M is designed to endure Nordic snow and slush. The luminaire is manufactured in Finland and it fulfils the NMF LED luminaire requirements.

PURPOSE: Outdoor lighting, Parking

INSTALLATION: Pole, Wall surface

Ask for a quote/offer

Benefits and suitability

Benefits

Vega M is an energy-efficient, sustainable luminaire with outstanding customisation opportunities. With all the power and light distribution options combined, the luminaire has well over a million possible configurations. Vega M adapts to future Smart City needs. The luminaire may be equipped with Zhaga and NEMA sockets.

Suitability

Vega M is suitable for various street- and area lighting needs including city streets and roads in urban and rural areas.

Model	Type Code	Initial CLO power consumption	Average CLO power consumption	End CLO power consumption	Luminous flux	Luminaire Efficacy	Lifetime	Operating temperature
VEGA M	GLVMS50^(A	50 W	50 W	50 W	7630 lm	153 lm/W, 350mA*	L100, C10 100 000 h	-40 - +50°C
VEGA M	GLVMS66^(A	65 W	66 W	66 W	10100 lm	155 lm/W, 350mA*	L100, C10 100 000 h	-40 - +50°C
VEGA M	GLVM67^(B	66 W	67 W	67 W	10300 lm	156 lm/W, 350mA*	L100, C10 100 000 h	-40 - +50°C
VEGA M	GLVM99^(B	98 W	99 W	99 W	15350 lm	157 lm/W, 350mA*	L100, C10 100 000 h	-40 - +50°C
VEGA M	GLVMS102^(A	99 W	101 W	102 W	13680 lm	138 lm/W, 700mA	L100, C10 100 000 h	-40 - +40°C
VEGA M	GLVM130^(B	127 W	129 W	130 W	20090 lm	158 lm/w, 350mA*	L100, C10 100 000 h	-40 - +45°C
VEGA M	GLVMS135^(A	131 W	133 W	135 W	18140 lm	138 lm/W, 700mA*	L100, C10 100 000 h	-40 - +40°C
VEGA M	GLVM166^(B	159 W	163 W	166 W	24100 lm	152 lm/W, 450mA*	L100, C10 100 000 h	-40 - +30°C
VEGA M	GLVMS168^(A	158 W	163 W	168 W	20780 lm	132 lm/W, 880mA*	L100, C10 100 000 h	-40 - +25°C

Notes:

The nominal luminous flux is the indicative LED luminous flux, based on information provided by the LED manufacturer, with 4000K colour temperature and CRI70 colour rendering. The real luminous flux of the luminaire depends on its environment (e.g. temperature or impurities), the colour temperature and colour rendering of the LED as well as the optical efficiency of the luminaire. All values in ambient temperature of +25°C with CLO constant light output control and light distribution V02 or 12. Luminous flux tolerance +-5%, power tolerance +-5%.

A) Optic family A (for example 07)

B) Optic family B (for example V07)

*) LED driving current

Luminous flux factors:
LED 3000K CRI70 = 0,91
LED 5000K CRI70 = 1,00

Model	Type Code	Length (L)	Height (H)	Width (W)	Weight	Wind surface area
VEGA M	GLVMS50^(A	559 mm	78 mm	320 mm	8,7 kg	1789 cm²
VEGA M	GLVMS66^(A	559 mm	78 mm	320 mm	8,9 kg	1789 cm²
VEGA M	GLVM67^(B	559 mm	78 mm	320 mm	8,7 kg	1789 cm²
VEGA M	GLVM99^(B	559 mm	78 mm	320 mm	9,3 kg	1789 cm²
VEGA M	GLVMS102^(A	559 mm	78 mm	320 mm	9,3 kg	1789 cm²
VEGA M	GLVM130^(B	559 mm	78 mm	320 mm	9,7 kg	1789 cm²
VEGA M	GLVMS135^(A	559 mm	78 mm	320 mm	9,7 kg	1789 cm²
VEGA M	GLVM166^(B	559 mm	78 mm	320 mm	9,6 kg	1789 cm²
VEGA M	GLVMS168^(A	559 mm	78 mm	320 mm	9,6 kg	1789 cm²

Colour Temperature:	3000 K, 4000 K, 5000 K ⁽¹
Colour Rendering Index:	R_A≥ 70
Light source shield:	Toughened glass
IP class:	IP66
IK class:	IK08
Supply voltage:	220-240 Vac
Frequency:	50-60 Hz
PF:	>0.93
THD:	<10%
Overvoltage Prot.:	10kV L/N-Ground & 6kV L-N

Connection:	Luminaire internal terminal block. Installation cable as an option.
Dimmability:	ON/OFF, DALI, AstroDIM, StepDIM, MainsDIM
Colour:	RAL9006, other RAL colours as an option.
Material of the luminaire body:	Aluminium
Guarantee:	8 years
Accessories (Installation):	Tube bracket, T-adapter, Pole adapter diam 76 mm -> 60 mm, Ceiling bracket, Wall bracket, 9905253 Vega flood Bracket, 9910082 Pipe Bracket
